Part No. 786717 WJP HP 9
GTIN 4013364438965, Customs tariff No. (EU): 42032910, Gross weight: 501.33 g, PU: 1.00 Pa
Technical data
High-pressure resistant | ≤ 1000 bar |
Size | 9 (L) |
Material | Multi-layer laminate, Kevlar |
Type | waterproof |
Standards / test principles | EN 420, EN 388, EN 13034 (Typ 6 ), GS-IFA-P15 (based on) |
Test parameters according to GS-IFA-P15 | flat jet nozzle type B |
– Distance (nozzle – surface of test sample) | 7.5 cm |
– Angle (high-pressure water jet) | 15 ° |
– Speed (feed) | 0.5 m/s |
– Quantity of water (high-pressure water jet) | 22 l/min |
– Pressure (high-pressure water jet) | 1200 bar* |
(*) The test against high pressure water jet penetration is performed with a safety factor of 1,2. |
Part No. 786718 WJP HP 10
GTIN 4013364439108, Customs tariff No. (EU): 42032910, Gross weight: 530.27 g, PU: 1.00 Pa
Technical data
High-pressure resistant | ≤ 1000 bar |
Size | 10 (XL) |
Material | Multi-layer laminate, Kevlar |
Type | waterproof |
Standards / test principles | EN 420, EN 388, EN 13034 (Typ 6 ), GS-IFA-P15 (based on) |
Test parameters according to GS-IFA-P15 | flat jet nozzle type B |
– Distance (nozzle – surface of test sample) | 7.5 cm |
– Angle (high-pressure water jet) | 15 ° |
– Speed (feed) | 0.5 m/s |
– Quantity of water (high-pressure water jet) | 22 l/min |
– Pressure (high-pressure water jet) | 1200 bar* |
(*) The test against high pressure water jet penetration is performed with a safety factor of 1,2. |
Part No. 786719 WJP HP 11
GTIN 4013364439115, Customs tariff No. (EU): 42032910, Gross weight: 533.67 g, PU: 1.00 Pa
Technical data
High-pressure resistant | ≤ 1000 bar |
Size | 11 (XXL) |
Material | Multi-layer laminate, Kevlar |
Type | waterproof |
Standards / test principles | EN 420, EN 388, EN 13034 (Typ 6 ), GS-IFA-P15 (based on) |
Test parameters according to GS-IFA-P15 | flat jet nozzle type B |
– Distance (nozzle – surface of test sample) | 7.5 cm |
– Angle (high-pressure water jet) | 15 ° |
– Speed (feed) | 0.5 m/s |
– Quantity of water (high-pressure water jet) | 22 l/min |
– Pressure (high-pressure water jet) | 1200 bar* |
(*) The test against high pressure water jet penetration is performed with a safety factor of 1,2. |
Part No. 786720 WJP HP 12
GTIN 4013364439122, Customs tariff No. (EU): 42032910, Gross weight: 559.33 g, PU: 1.00 Pa
Technical data
High-pressure resistant | ≤ 1000 bar |
Size | 12 (3XL) |
Material | Multi-layer laminate, Kevlar |
Type | waterproof |
Standards / test principles | EN 420, EN 388, EN 13034 (Typ 6 ), GS-IFA-P15 (based on) |
Test parameters according to GS-IFA-P15 | flat jet nozzle type B |
– Distance (nozzle – surface of test sample) | 7.5 cm |
– Angle (high-pressure water jet) | 15 ° |
– Speed (feed) | 0.5 m/s |
– Quantity of water (high-pressure water jet) | 22 l/min |
– Pressure (high-pressure water jet) | 1200 bar* |
(*) The test against high pressure water jet penetration is performed with a safety factor of 1,2. |
Part No. 786721 WJP HP 13
GTIN 4013364439139, Customs tariff No. (EU): 42032910, Gross weight: 562.15 g, PU: 1.00 Pa
Technical data
High-pressure resistant | ≤ 1000 bar |
Size | 13 (4XL) |
Material | Multi-layer laminate, Kevlar |
Type | waterproof |
Standards / test principles | EN 420, EN 388, EN 13034 (Typ 6 ), GS-IFA-P15 (based on) |
Test parameters according to GS-IFA-P15 | flat jet nozzle type B |
– Distance (nozzle – surface of test sample) | 7.5 cm |
– Angle (high-pressure water jet) | 15 ° |
– Speed (feed) | 0.5 m/s |
– Quantity of water (high-pressure water jet) | 22 l/min |
– Pressure (high-pressure water jet) | 1200 bar* |
(*) The test against high pressure water jet penetration is performed with a safety factor of 1,2. |
