HSA 205 High-Voltage Indicator
:quality(98)/dehn.nl/store/f/26704718/HDVORSCHAU/767555a1_16-9.jpg)
:quality(98)/dehn.nl/store/f/26704718/HDVORSCHAU/767555a1_16-9.jpg)
- For contactlessly verifying that switchgear installations and high-voltage overhead lines are dead
- Wide nominal voltage range
Details
:quality(98)/dehn.nl/store/f/26704719/HDVORSCHAU/767555az1_E.jpg)
:quality(98)/dehn.nl/store/f/26704719/HDVORSCHAU/767555az1_E.jpg)
:quality(98)/dehn.nl/store/f/26704720/HDVORSCHAU/767552_Spannungsbereich_E.jpg)
:quality(98)/dehn.nl/store/f/26704720/HDVORSCHAU/767552_Spannungsbereich_E.jpg)
Part No. 767552 HSA205 U 1 420 STK
GTIN 4013364115736, Customs tariff No. (EU): 90303370, Gross weight: 2.50 kg, PU: 1.00 Stk
:quality(98)/dehn.nl/store/f/26704726/HDVORSCHAU/767552_T.jpg)
:quality(98)/dehn.nl/store/f/26704726/HDVORSCHAU/767552_T.jpg)
:quality(98)/dehn.nl/store/f/26704727/HDVORSCHAU/767552m_D.jpg)
:quality(98)/dehn.nl/store/f/26704727/HDVORSCHAU/767552m_D.jpg)
Technical data
| Nominal voltage range (UN ) | 1 ... 30 / 30 ... 220 / 110 ... 420 kV |
| Frequency | 50 Hz |
| Total length (lG ) | 950 mm |
| Insulating clearance (lI ) | 540 mm |
Part No. 767547 HSA205 U 1 420SN7608
GTIN 4013364158276, Customs tariff No. (EU): 90303370, Gross weight: 2.00 kg, PU: 1.00 Stk
Images
:quality(98)/dehn.nl/store/f/26704748/HDVORSCHAU/767552_T.jpg)
:quality(98)/dehn.nl/store/f/26704748/HDVORSCHAU/767552_T.jpg)
:quality(98)/dehn.nl/store/f/26704749/HDVORSCHAU/767552m_D.jpg)
:quality(98)/dehn.nl/store/f/26704749/HDVORSCHAU/767552m_D.jpg)
Technical data
| Nominal voltage range (UN ) | 1 ... 30 / 30 ... 220 / 110 ... 420 kV |
| Frequency | 60 Hz |
| Total length (lG ) | 950 mm |
| Insulating clearance (lI ) | 540 mm |
